HL, CJ, SF Series Vacuum Coating Continuous Production Line

Date:2016-01-16 13:03:48 Hits:2772
HL, CJ, SF Series Vacuum Coating Continuous Production Line

Operational principle

1. Thecontinuous glass coating production line is used mainly for appliance glass,furniture glass, automotive glass, a large area mirror, functional ordecorative glass products such as the surface of the metal film, alloy film,multilayer dielectric film or continuous vacuum coating, common for the coatedreflective film, color film, translucent film. Products have the effects ofinsulation, filters, energy saving, decorative, corrosion resistance and so on.

2. Theamorphous silicon solar cell production line is mainly used for the productionof large photovoltaic glass template to ordinary glass substrate was preparedthrough atmospheric pressure CVD or PVD oxide transparent conductive film, andPECVD can prepare the various types of amorphous silicon film, magnetronsputtering AZO film or electrodes, intermediate lines of the membrane using alaser grooving, through testing and packaging to complete a large area cellmodule manufacturing process, the whole process is not more than ten. Thancrystalline silicon cell production process is much simpler. The siliconmaterial utilization rate is improved for several times, the manufacturing costof crystalline silicon cells are only about 1/3.

3. PC/ PMMA / PET sheet coated coating production line for Al, Cr, SUS, Ni, Sn, Tiand alloys such as a metal film, and can be coated by the reaction SiO2, TiO2and other dielectric film, the production process is fully automaticcontinuous. Company can provide users with a substrate size, technicalrequirements and capacity needs, and so a full set of equipment specificallydesigned and manufacturing.

Thisdevice is also applies to coat on a glass substrate or planar work piece suchas the mobile phone keypad and other products coating.

4.Low-e coating production line (ie, radiation protection glass curtain wallcoating production line) applies to use in large flat float glass coated metalsheet membrane, composite film, alloy film, multilayer dielectric film, butalso in small bend curved glass coating.

5. ITOconductive glass coating production line is applies to the high-quality floatglass coated TN-type, STN-type, TP type and CF-type transparent conductivefilm. It applies to coat on the Si02/IT0 film, the production process is fullyautomated continuous. According to the user-supplied substrate size, technicalrequirements and capacity needs, and so all the equipment design andmanufacturing expertise.

Applications

Features

technical parameter
