The electron beam heating vacuum roll-to roll coating equipment is used for evaporation of a large number of high melting point substances such as SiO2. The roll-to-roll coating equipment based on the magnetron sputtering principle has low production efficiency,but has the advantages of wide coating adaptation range and strong film adhesion.

Resistance heating evaporative winding(Roll-to-Roll) type vacuum coating equipment. Induction heating evaporative vacuum winding coating equipment. Electron beam heating evaporative vacuum coiling coating equipment.Magnetron sputtering vacuum winding coating equipment. The electron beam heating vacuum roll-to roll coating equipment is used for evaporation of a large number of high melting point substances such as SiO2. The roll-to-roll coating equipment based on the magnetron sputtering principle has low production efficiency,but has the advantages of wide coating adaptation range and strong film adhesion.

1. CJRW series is mainly used in flexible circuit boards, ITO transparent conductive film, film capacitors, car film, thin film solar cells, flexible solar cells and so on. Using magnetron sputtering technology, with DC, IF or RF magnetron sputtering system for coating the  metal film, conductive film, total film, dielectric film, etc.
2. SFRW series applies to use in PET, PVC, PI, CPP coated surface of a transparent film such as high resistance packaging film, security film, Symphony film, optical film, a dielectric film using the electron beam evaporation technology,
3. ZFRW series is mainly used in printing and packaging film, wrapping paper, metallic yarn, capacitor film, functional films and so on. The machine is used by advanced high frequency induction evaporation or continuous wire feed evaporation technology, and the whole prcess is automatically controlled.

The winding and coating equipment has the characteristics of smooth operation, flat retracting and coating, uniform film layer, short production cycle, low energy consumption, easy operation and maintenance, stable performance and so on. The winding system adopts high precision DC or AC frequency conversion speed regulation, which has the characteristics of smooth operation, high speed, no scratch and no wrinkle to the original coil, and neat winding end face. Tension control adopts imported digital tension control system, which has the characteristics of constant tension and linear speed and fast operation; Powerful and efficient pumping system with energy saving maintenance pump.
